MLZ2012M2R2HT000 Images are for reference only, See Product Specifications
| Part Number | MLZ2012M2R2HT000 |
|---|---|
| Manufacturer | TDK Corporation |
| Description | FIXED IND 2.2UH 600MA 160 MOHM |
| Data sheet |  MLZ2012M2R2HT000.pdf |
| Category | Inductors, Coils, Chokes |
| Family | Fixed Inductors |
| Series | MLZ |
Buy the MLZ2012M2R2HT000 TDK Corporation on Chip Source Co., LIMITED,we are TDK Corporation Corporation distributor,we sales new&original and offer 24 hours service,180 days warranty date, send the MLZ2012M2R2HT000 within 24 hours,please contact our sales team or send email to [email protected] Hope we can cooperate in the future.
| Part Status | Active |
|---|---|
| Type | Multilayer |
| Material - Core | Ferrite |
| Inductance | 2.2µH |
| Tolerance | ±20% |
| Current Rating | 600mA |
| Current - Saturation | 400mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 208 mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 100MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Frequency - Test | 2MHz |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 (2012 Metric) |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height - Seated (Max) | 0.041" (1.05mm) |
| Shipment | UPS/EMS/DHL/FedEx Express. |
| Condtion | New original factory. |
| RFQ Email | [email protected] or Inquires online |
